7
3.6 GPIO/Option Slot – Ready
for Various Extensions
The GPIO interface provides a universal connec-
tion that could, for example, link with the house
system’s control unit. The Option slot accepts
future extension hardware such as CobraNet ports
and Ethersound interfaces, ensuring your invest-
ment in FIRNET yields long-term returns on your
investment.
4.1 Fundamentals
FIRNET LIPAN software runs on WIN XP and
enables you to remotely monitor and control
anything from a single controller to an audio
network comprising up to 100 devices, and all this
with remarkable clarity and convenience. It handles
so intuitively that you’ll be able to achieve great
results the fi rst time out! The standard Ethernet
X and II ports on the rear panel let you connect
several FIRNET controllers to remotely control and
monitor entire networks. For details on network
cable connections, see chapter 6.3, „Rear Panel, PC
Ethernet Control Ports.“
With a connected PC running LIPAN software, you
can then remote-control this network; that is, moni-
tor all parameters set and indicated at the FIRNET
and adjust all controller settings at your PC. LIPAN
software also performs further convenient functions
such as simultaneously manipulating several FIR-
NET controllers assigned to groups and equalizing
the entire system with a fully parametric IIR-EQ for
every controller. Read the LIPAN software manual to
learn more about what it can do for you.
4.2 IP Address
Every device has a predefi ned IP address that may
be edited at the device. Every controller in the
network is identifi ed and addressed individually by
its freely assignable name and unique IP address.
Controllers are integrated via a LAN or WLAN.
4.3 Database of Filter Sets for
Specific Speakers
The FIRNET features an extendible database
archiving functions for equalization, phase
correction, and power handling capacity specifi ca-
tions of different HK AUDIO speakers and sound
reinforcement systems.
The controller stores up to 100 fi lters tuned for
specifi c speakers. A simple mouse click adds setups
to and removes setups from the fi lter database. The
database lists these speaker-specifi c fi lters by their
HK AUDIO speaker series names for easy access.
All settings may be stored to the PC as a backup,
ensuring they remain accessible at any time.
4.4 Total Control
The main window provides a clear view of every
networked setup, including all connected control-
lers and confi gured groups. A simple mouse click
in the network view selects any controller or group
for editing.
4.5 Fast Access
The desktop offers a channel strip view of all the
controller’s functions called the controller window.
A mouse click changes speaker fi lters, levels, mute
and solo groups, and phases in real-time, without
a lot of searching and thumbing through operating
manuals. The Admin menu clearly lists all parame-
ters such as IP-address, controller name, and audio
source, as well as units for temperature, delay, and
the like.
4.6 Grouping Controllers
Several controllers may be grouped in 16 different
groups, making it easy to adjust parameters such as
levels and delay times collectively. The main window
affords a clear view of all routings.
4.7 Database of Scenes for
Specific Events
The FIRNET features a database with ten memory
slots for setups for specifi c events called scenes.
They are handy tools for recurring events at the
same venues because the speed up audio system
setup and ensure every event benefi ts from the
same high quality of audio performance.
4.8 Stereo Controller EQ
LIPAN also provides also an IIR stereo EQ with
four fully parametric and two multifunctional
bands (peak, shelf, and cut) for every controller in
the network. They serve to equalize and adapt the
system to suit the given venue. You can set up a
WLAN link to check settings at different positions in
the audience area and adjust them immediately in
real time via this online link.
4 LIPAN PC Software for Remote Control and
Monitoring
English
