HSI #780-0867 FireSpy Tracker Installation Manual
22
AC power
input
Battery cable
Non-power-limited areas are gray.
Segregate power-limited wiring from
non-power-limited wiring by at least
1/4 inch.
CAB
MB
BATTERY BATTERY
USB
PDC
SECNDRY
PHONE
PRIMARY
PHONE
B+ A+ A- B- B+ A+ A- B-
NAC2
B+ A+ A- B-
NAC3 NAC1
+ - - + RS485 RS485
A+ A- B+ B-
SLC
NC
COM
NO
NC
COM
NO
NC
COM
NO
-
+
+
-
RELAYS
REL
A
Y1
REL
A
Y2
AUX I/O
B
A
TT
TROUBLE
RC
290-0160
Figure 3-4: Wire routing on T1000
