HSI #780-0867 FireSpy Tracker Installation Manual
14
T8000-A-CAB T8000-EXP5 T8000-EXP5N
Size (inches)
Overall
Backbox W x H x D
11.37 x 9.94 x 2.8
10 x 8.5 x 2 W x H x D
15.88 x 19.44 x 3.8
14.5 x 18 x 3 W x H x D
7.38 x 19.5 x 2.88
6 x 18.13 x 3.13
Knockouts
(1-1/8 dia) 3 top
3 bottom 4 top
4 bottom 2 top
2 bottom
4 each side
Module Quantity of modules that may be mounted
T8000-CM 1
T8000-RC 5 5
T8000-RAN 1
2.4 Service use
The Tracker is suitable for the following NFPA72 service uses:
Table 2-21: Service uses.
Type Service Signaling Required Equipment
Local (PPU) A, M, SS, WF, R Non-coded, march time
Proprietary (PPU) A, M, SS, WF, R Multiplex
Remote Station (PPU) A, M, SS, WF, R DACT
Reverse polarity T-UDACT*
UCT
Central Station (PPU) A, M, SS, WF, R DACT T-UDACT*
Auxiliary (PPU) A, M, WF, R N/A UCT
Abbreviations for services:
A = Automatic fire alarm
M = Manual fire alarm
SS = Sprinkler supervisory service
WF = Waterflow alarm
R = Releasing device service
* The T-UDACT is required equipment for these uses on the MBC and MBCLC. It is not required for these uses on the MB
because the MB has a built-in DACT.
2.5 Listings and approvals
ETL Listed: Standard UL864
CSFM Listed 7165-0476:172 (T2000, T8000)
MEA/BSA MEA 43-05-E, 43-05-E Vol 2 (T2000, T8000)
