HSI #780-0867 FireSpy Tracker Installation Manual
8
The main board contains (1) common alarm relay output, (1) common supervisory alarm relay output, and
(1) common trouble relay output, as well as a connection for up to (5) relay modules (T8000-RC).
Table 2-9: Output relay specifications (MB / MBC / MBCLC)
Parameter Rating
Type Form C (SPDT)
Contact rating
MBC / MBCLC
resistive load, PF=1.0
inductive load, PF=0.4
MB
resistive load, PF=1.0
10A @ 30VDC
10A @ 240VAC*
3A @ 240VAC*
2A @ 30VDC
* Limited to 50VDC due to spacing
Table 2-10: SLC specifications (MB / MBCLC)
Parameter Rating
Loop output voltage 32V @ 10kHz
Max loop output current 400mA max
Max loop capacitance 0.5uF
Max loop impedance (total per loop) 40 ohms
Environment
UL864 location
Temperature range
Maximum relative humidity
Indoor, dry
32 to 120° F
93%
* See Appendix C Wire Selection for suggested wiring distances.
2.3.2 Display board (T-PDC)
The display board may mount either inside the enclosure door so its buttons are accessible with the door
closed or on the chassis assembly (MBC or MBCLC only) so it is accessible after unlocking and opening
the enclosure. When the PDC is mounted on the door and connected to the keyswitch, the keyswitch
must be activated to enable keypad access to the system’s security-sensitive control functions.
2.3.3 Network Communications adapter (T8000-NCA)
The network communications adapter is used with each panel in a networked system. It allows the
connected panel to communicate with other panels on the panel network.
Table 2-11: Communications adapter (T8000-NCA) specifications.
Parameter Rating
Input voltage Regulated 24 DC
Input current draw 60 mA
Max impedance, RS485 communication wiring, total 40 ohms*
Max capacitance, RS485 communication wiring 0.3 uF*
Environment
UL864 location
Temperature range
Maximum relative humidity
Indoor, dry
32 to 120° F
93%
* See Appendix C Wire Selection for suggested wiring distances.
