HSI #780-0923

FireSpy Tracker Operation Manual

16

5.5

Menu 2.2: Silent Walk Test

While on this screen, devices that go into alarm are displayed on the
screen.

Available keys

C / D

browse through the items placed into alarm

E

go back to parent menu

RESET

exit the menu system and reset the panel

Walk Test Active

Press to

end Walk Test

5.6

Menu 2.3: Test NACs

Available keys

C / D

highlight the NAC you wish to test

A / B

toggle testing on the highlighted NAC

E

go back to parent menu

RESET

exit the menu system and reset the panel

NAC Immediate On/Off

NAC1: OFF NAC2: OFF

NAC3: OFF NAC4: OFF

5.7

Menu 2.4: Test Relays

Available keys

C / D

highlight the relay you wish to test

A / B

toggle testing on the highlighted relay

E

go back to parent menu

RESET

exit the menu system and reset the panel

Relay Test

Trouble Relay: OFF

Alarm Relays: OFF

5.8

Menu 2.5: Test LCD Display

As soon as you enter this menu option, the PDC screen will alternately
turn all pixels on and all pixels off row by row and also turn all PDC LEDs
on and off.

Available keys

E

go back to parent menu

RESET

exit the menu system and reset the panel


(alternately filled

and cleared)

5.9

Menu 2.5: Drill Test

The drill test will activate all outputs that are configured to operate during
a fire drill.

Available keys

E

go back to parent menu

RESET

exit the menu system and reset the panel

<<< Fire Drill >>>

Press to

end Fire Drill
