1-33F-7
BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL JULY, 2011
VALVE KIT 2-6346
Kioti LB2214, LB2614, LK2552, LK2554,
LK3054, LK3504 & LK3054XS
REF. PART
NO. NO. DESCRIPTION QTY.
1 53461 Valve, Prince LVR (1600 PSI) 1
2 ------ Capscrew, 3/8-16 x 2-1/2 1
3 43517 Handle, Standard 1
4 43451 Angle, Decal Mounting 1
5 ------ Locknut, 3/8-16 2
6 ------ Capscrew, 5/16-18 x 3/4 4
7 ------ Lockwasher, 5/16 4
8 38902 Ball, Handle 1
9 32845-7 Fitting, Elbow, 9/16-18 JIC x 3/4-16 O-Ring, 90° 1
10 36766 Fitting, Banjo 3
11 36386-7 Hose, 3/8 x 32 (Power Beyond) 1
12 43454-2 Hose, 3/8 x 36 (Pressure & Tank) 2
13 ------ Hex Nut, 7/16-20 1
14 43635 Boot 1
15 6147-4 Coupler, Female 4
16 36240-9 Spiral Band, Plastic, Blue, 1” 1
36240-10 Spiral Band, Plastic, Red, 1” 1
36240-11 Spiral Band, Plastic, Yellow, 1” 1
36240-12 Spiral Band, Plastic, Green, 1” 1
17 36336-1 Hose, 3/8 x 78 4
18 36240-5 Spiral Band, Plastic, Blue, 5/8 1
36240-6 Spiral Band, Plastic, Red, 5/8 1
36240-7 Spiral Band, Plastic, Yellow, 5/8 1
36240-8 Spiral Band, Plastic, Green, 5/8 1
19 6137-4 Coupler, Male 4
20 43453 Decal, Single Handle Control 1
21 8137-1 Strap, Adjustable, 3/16 x 11 3
22 39280-7 Fitting, Adapter, 3/4-16 O-Ring x 3/8 NPT 4
23 44168 Plate, Valve Mounting 1
24 44334 Bracket, Valve Mounting 1
25 34853-2 Sleeve, Nylon 66”
26 7438-1 Tarp Strap 1
27 ------ Capscrew, 3/8-16 x 1” 1
28 ------ Locknut, 1/2-13 2
29 ------ Capscrew, 1/2-13 x 2-1/2 2
30 ------ Flatwasher, 1/2 2
31 32844-1 Fitting, Adapter, 9/16 O-Ring x 9/16-18 JIC 3
32 43763 Bolt, Flow 3
33 36769 Seal Ring, Copper 3
34 6000-82 O-Ring, 3/8 x 1/2 x .070 3
35 8137-5 Strap, Adjust, 1/2 x 34 1
36 46533 Orifice Restrictor Kit (.094 Dia.) 1
