1-33B-15
BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL JULY, 2011
MOUNTING KIT 2-6054
Kubota L2250, L2550DT, L2550GST,
L2650GST, L2950GST FWA
REF. PART
NO. NO. DESCRIPTION QTY.
1 42917+ Bracket, Front Mounting 1
2 39086 Bracket, Mid Mounting 1
3 39087 Spacer, Mid Mounting 2
4 ------ Capscrew, Metric, M14-1.5 x 50 (RH Side Only) 4
5 ------ Capscrew, Metric, M14-1.5 x 40 8
6 ------ Lockwasher, 9/16 12
7 36891-1 Bracket, Left Reinforcement 1
8 36891-2 Bracket, Right Reinforcement (Not Shown) 1
9 ------ Capscrew, 1/2-13 x 1-1/2 10
10 ------ Flatwasher, 1/2 4
11 ------ Locknut, 1/2 -13 10
