FITS WATTS VALVES
WATTS MODEL #
DIMENSIONS
12" CLEARANCE LENgTH x WIDTH x HEIgHT
HEATERS
WEIgHT LBS.
MOUNTINg
PAD SIzE
Fiberglass
Thru
3
⁄
4
"
007/LF007, 009/LF009, 909/LF909, 719/LF719, 919/LF919
WB-75
19" x 11" x 22"
30W
30
28" x 20"
Thru 1"
007/LF007, 009/LF009, 909/LF909, 719/LF719, 919/LF919
WB-1
27" x 13" x 23"
60W
40
36" x 22"
Thru 1
1
⁄
2
"
007/LF007, 009/LF009, 909/LF909, 719/LF719, 919/LF919
WB-1.5
33" x 21" x 25"
60W
60
44" x 32"
Thru - 2"
007/LF007, 009/LF009, 909/LF909, 719/LF719, 919/LF919
WB-2
39" x 13" x 28"
90W
55
50" x 24"
3
⁄
4
" - 1"
008/LF008, 800/LF800, 288/LF288, 289/LF289
WB-PVB1
18" x 9" x 18"
30W
25
19" x 27"
(Increases height by 6")
WB-PVB T1
18" x 9" x 24"
30W
28
19" x 27"
1
1
⁄
4
" - 2"
800 / 288
WB-PVB2
26" x 12" x 20"
60W
30
21" x 35"
(Increases height by 8")
WB-PVB T2
26" x 12" x 28"
60W
35
21" x 35"
2
1
⁄
2
" - 3" all
007/LF007, 009/LF009, 909/LF909
4" 774 NRS / OSY / DCDA
4" 994NRS, 3" 775NRS / OSY / DCDA ,
3" 995NRS, 4" 775NRS, 4" 994NRS,
2
1
⁄
2
" - 3" 757DCDA, 2
1
⁄
2
" - 3" 957QT,
2
1
⁄
2
" - 3" 957RPDA
WB-N3
70" x 26" x 45"
1000W
285
82" x 38"
4" 994OSY / RPDA, 4" 775OSY / DCDA,
3" 995OSY / RPDA
WB-E3
70" x 26" x 55"
1500W
375
82" x 38"
2
1
⁄
2
" - 3" 957N NRS / OSY / BFG / QT,
4" 957N NRS / BFG / QT
WB 3000
45" x 35" x 35"
1000W
265
57" x 47"
4" 957N OSY, 4" 757DCDA
WB 4000
53" x 44" x 44"
1000W
290
65" x 56"
Aluminum
4" 709/LF709 NRS / OSY / DCDA,
4" 909/LF909 NRS / OSY / RPDA,
6" 774NRS / OSY / DCDA,
6" 994NRS, 6" 775NRS,
6" 995NRS, 8" 775NRS,
4" 757NRS / OSY, 6" 757NRS / OSY / BFG,
8" 757NRS / BFG, 4" 757DCDA, 6" 757DCDA,
4" 957OSY, 6" 957NRS, 8" 957NRS
WB-N4
90" x 32" x 50.5"
1900W
400
102" x 44"
6" 957OSY, 6" 957RPDA
WB-E4
90" x 32" x 57.5"
1900W
435
102" x 44"
6" 709/LF709 NRS / OSY / DCDA,
6" 909/LF909 NRS / OSY / RPDA,
8" 774 / 994NRS, 10" 774 NRS,
10" 957NRS
WB-N6
105" x 36" x 53"
1900W
480
117" x 48"
6" 994 OSY / RPDA, 8" 774 OSY / DCDA,
10" 994 NRS, 6" 775OSY / DCDA,
8" 775OSY / DCDA, 6" 995OSY / RPDA,
8" 757OSY, 10" 757NRS, 8" 757DCDA,
8" 957OSY, 8" 957RPDA
WB-E6
105" x 36" x 64"
3000W
530
117" x 48"
8" 709/LF709, 909/LF909 NRS
WB-N8
118" x 40" x 58"
3000W
565
130" x 52"
8" 709/LF709 OSY / DCDA, 8" 909/LF909 / 994OSY / RPDA,
10" 774OSY / DCDA,
8" 757OSY / DCDA, 8" 957OSY / RPDA,
10" 757NRS, 10" 957NRS
WB-E8
118" x 40" x 74"
3000W
625
130" x 52"
10" 709/LF709, 909/LF909 NRS
WB-N10
142" x 42" x 65"
3000W
620
154" x 54"
10" 709/LF709 OSY / DCDA, 10" 909/LF909 / 994OSY / RPDA,
10" 757OSY / DCDA, 10" 957OSY / RPDA
WB-E10
142" x 42" x 85"
3800W
700
154" x 54"
2
1
⁄
2
" - 3" 757N OSY, 4" 757N NRS / BFG,
6" 757N NRS / BFG, 6" 957N BFG
WB 4000AN
53" x 33" x 44"
1000W
280
65" x 45"
4" 757N OSY, 3" 757N DCDA, 6" 957N NRS,
8" 957N NRS, 2
1
⁄
2
" - 3" 957N RPDA, 4" 957N RPDA
WB 4000AE
53" x 44" x 44"
1000W
340
65" x 56"
8" 757N NRS, 4" 957 QT
WB 6000AN
62" x 39" x 46"
1500W
350
74" x 51"
6" 757N OSY, 6" 757N DCDA, 6" 957N OSY,
8" 957N NRS, 6" 957N RPDA
WB 6000AE
62" x 53" x 46"
1500W
440
74" x 65"
3
Dimensions
(all enclosures are available less heat - contact factory or your local Watts representative for details)
