Parts List
To order replacement
parts, contact
1-800-800-7310 or visit
www.mtdproducts.com
NOTE: This Operators
Manual covers a range
of product specifica-
tions for various
models. Characteristics
and features discussed
and/or illustrated in this
manual may not be ap-
plicable to all models.
MTD LLC reserves the
right to change product
specifications, designs
and equipment without
notice and without
incurring obligation.
Ref.
No.
Part No. Description
1. 728-0175†† Pop Rivet
2. 681-0095† Chipper Shredder Chute
731-1899†† Chipper Shredder Chute
3. 735-0249†† Chute Flap
4. 781-0633†† Chute Flap Strip
5. 681-0068A†† Chipper Chute Assembly
6. 710-0751†† Hex Cap Screw 1/4 -20 x.620
7. 712-3027†† Hex Lock Nut 1/4-20
8. 710-0106†† Hex Cap Screw 1/4-20 x 1.25
9. 736-0173†† Flat Washer.28 ID x.74 OD
10. 736-0242 Bell Washer.340 ID x.872 OD
11. 712-3010 Hex Nut 5/16-18
12. 749-1004†† Support Brace
13. 712-3004A Hex Lock Nut 5/16-18
14. 710-0805† Hex Cap Screw 5/16-18 x 1.50
710-3180†† Hex Cap Screw 5/16-18 x 1.75
15. 736-0170 Bell Washer 5/16 x 1.0
16. 736-0366†† Flat Washer
17. 738-0814† Axle Assembly
738-0813†† Axle Assembly
18. 750-0786† Spacer
19. 734-1600† Wheel Comp., 10.0 x 2.5 Plastic
734-1845†† Wheel Complete, 10.0 x 4.0 Gray
20. 726-0214 Push Cap
21. 681-0184A† Frame
681-0183A†† Frame
22. 736-0451†† Washer,.320 ID x.93 OD
23. 710-0502A Screw, 3/8-16 x 1.250
24. 737-0195† Elbow Fitting
25. 737-0298†† Oil Drain Pipe
26. 737-0132†† Oil Drain End Cap
27. 681-0133* Tongue Hitch Mount
28. 681-0134A* Base Hitch Mount
29. 710-3001* Hex Cap Screw, 3/8-16 x.88
30. 711-0299* Clevis Pin,.625 x 2.4
31. 711-0835* Clevis Pin,.50 x 4.62
32. 712-04065* Flange Lock Nut, 3/8-16
33. 732-0194* Spring Pin
34. 736-0133* Flat Washer,.411 x 1.25 x 1.0
35. 736-0169* Lock Washer, 3/8
— 723-0400 Safety Glasses (Not Shown)
— 664-04022† Chipper Bag Ass’y (Not Shown)
— 664-04023†† Chipper Bag Ass’y (Not Shown)
† Model Series 450
†† Model Series 460
* If Equipped
