6
STEP 4
System Start Up
Step A– Turn on water supply at angle stop and open the Adapt-
A-Valve™ . Turn faucet handle to the open position to start
the flow of water through the unit . Run 3 gallons of water
through the unit in order to flush out the normal black car-
bon fines (it will “sputter” until the air is purged out) from the
unit . Initially, the water may appear cloudy which is due to
tiny air bubbles and it will clear up shortly . Close the faucet
when finished .
Step B – Check for leaks . If you have any leaks, shut off the water
supply to your system, tighten any fittings / housings and
restart unit .
Check frequently over the next 24 hours to ensure no leaks are
present
Green Tube Connection
Step A – Locate green tube attached to the
Filter Module . Insert the open end
of the green 1 ⁄
4
" tube into the open
1 ⁄
4
" Quick-Connect fitting on the
Adapt-A-Valve™ making sure the
tube is pushed in all the way to the
tube stop .
Step B – Connect the green tube from the
Filter module to the Adapt-A-Valve™
that is connected to the angle stop
valve . Leave enough tube so it is not kinked and cut the
tube to the desired length .
STEP 5
UF Drinking System Module Mounting
Step A – Determine best location for
the UF Filter Module to be
mounted to allow for future
system maintenance . The
parts bag has 2 self-tapping
screws . Using an electric drill
with a Phillips bit, screw them
into the cabinet wall 6" apart
and 16" from the bottom of the
cabinet .
Note: Do not cut any UF system tubes at this time
