Watts U009 - Manual (Page 3)

Dimensions and Weights
U009QT
model size (dn) dimensions Weight
A B C
in. mm in. mm in. mm in. mm lbs. kgs.
U009QT 1 ⁄
2
15 12 13 ⁄
16
326 4 5 ⁄
8
117 3 7 ⁄
16
87 5.5 2.5
U009M2QT 3 ⁄
4
20 13 3 ⁄
4
349 5 127 3 3 ⁄
4
95 6 2.7
U009M2QT 1 25 17 3 ⁄
8
441 5 1 ⁄
2
140 3 1 ⁄
8
79 12.75 5.8
U009M2QT 1 1 ⁄
4
32 24 1 ⁄
2
622 7 3 ⁄
4
197 4 100 26.5 12.0
U009M2QT 1 1 ⁄
2
40 25 1 ⁄
2
648 7 3 ⁄
4
197 4 1 ⁄
4
108 28.75 13.0
U009M2QT 2 50 27 3 ⁄
8
695 7 3 ⁄
4
197 4 1 ⁄
4
108 32.75 14.9
A
C
B
d1
C
r A
d
U009AQT
model size (dn) 00 dimensions Weight
A C D D1 R
in. mm in. mm in. mm in. mm in. mm in. mm lbs. kgs.
U009AQT 3 ⁄
4
20 13 1 ⁄
8
333 3 1 ⁄
8
79 4 5 ⁄
8
117 4 3 ⁄
4
121 2 3 ⁄
8
60 12.50 5.7
U009M2AQT 1 25 13 1 ⁄
8
333 3 1 ⁄
8
79 5 1 ⁄
8
130 5 3 ⁄
16
132 2 3 ⁄
8
60 13.88 6.3
U009M2AQT 1 1 ⁄
2
40 15 3 ⁄
8
390 4 1 ⁄
4
108 7 3 ⁄
4
197 7 3 ⁄
4
197 3 1 ⁄
4
83 39.25 17.8
U009M2AQT 2 50 19 1 ⁄
4
489 4 1 ⁄
4
108 8 3 ⁄
8
213 8 3 ⁄
8
213 3 1 ⁄
4
83 39.25 17.8
