19
Form RESERVED FOR FUTURE USE
Form Clear RESERVED FOR FUTURE USE
The Setup Menu
The Setup Menu allows you to set or adjust label formating or printing defaults. You can
access any of the Setup menu functions by following the steps below:
1. Press the + keys to access the Setup menu.
The Setup menu appears on the LCD.
2. Use the <
>
> and <
?
> keys to move through the menu choices. The cursor
indicates the currently selected option.
NOTE: A downward pointing arrow on the right side of the LCD indicates that there
are more selections available below the currently highlighted choice. An upward
pointing arrow indicates that there are more selections available above the currently
highlighted choice. Up and down arrows appearing simultaneously indicate that there
are more selections available both above and below the currently hightlighted choice.
3. Press the key to access the sub-menu choices.
4. Use the <
>
> and <
?
> keys to move through the sub-menu choices. The cursor
indicates the currently selected option.
5. Press the key. Use the <
>
> and <
?
> keys select the desired menu
setting, then press to save your change. To exit without saving the change,
press either the key (sends you back to the text editor screen) or the
key (backs you out one level in the menu tree).
Setup Menu Options
The Setup Menu contains five sub-menu options for formating and printing your labels .
These options provide you with many ways to customize the formatting of your labels. See
Setup Menu Tree on page 19.
Printer
The Printer menu contains the following user options:
* Top Margin Adj: Adjusts first vertical print position from top of label.
* Left Margin Adj: Adjusts first horizontal print position from left edge of label.
** Cut Feed Adj: Adjusts vertical cut position between labels.
