Text mode
Original mode

Remark:

The ceiling mount can also be mounted using one of the 2 available bars (height
adjustment) and cable cover assy.
R9841260: short bar R822922 and cable cover assy .

min length = 445mm(17.52 inch)
max length = 810 mm(31.89 inch)

R9841261: long bar R822923 cable cover kit R984 .

min length = 845mm(33.27 inch)

max length = 1210 mm(47.64 inch

)

I

llustration of the Cable Cover Assy:

R826748

R826761

G229790 &
V3675126

R826749

R347968 (7X)

Z348001( 4X)

R826745

R347972 ( 4 X)

Note: The assembly is used only when ceiling mount is mounted along with
IQ bar for hiding and guiding the cables.
