9. The adjustment procedure for the rotation around central vertical axis can
also be done as explained below.
Loosen the 4 M3 screws N of cable cover and slide it down word.
Loosen the 4 bolts O. Rotate /adjust the projector clockwise or anti
clockwise. Tighten the 4 bolts O to secure the position. Slide up the
cable cover and fix 4 M3 screws N.
O
O
Rotate around
l R83578
5
10. fix the one end of safety chain into the projector’s Eye bolt and the other
end to the firm place in the ceiling.
