VS3 Series Retroreflective Mode
page 3
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
VS3 Series Retroreflective Mode Sensor Dimensions
35.2 mm
(1.39")
14.2 mm
(0.56")
7.3 mm
(0.29")
16.6 mm
(0.65")
13.6 mm
(0.54")
25.4 mm
(1.00")
16.4 mm
(0.65")
9 mm
(0.35")
4.5 mm
(0.18")
35.2 mm
(1.39")
14.2 mm
(0.56")
7.3 mm
(0.29")
15.6 mm
(0.61")
12.6 mm
(0.50")
25.4 mm
(1.00")
16.4 mm
(0.65")
9 mm
(0.35")
4.5 mm
(0.18")
VS3...5XLV VS3...5XLVQ
VS3...5XLP VS3...5XLPQ
With
Straight
QD Cable
With
Integral
Cable
With
Right-angle
QD Cable
47 mm
(1.9")
30 mm
(1.2")
75 mm
(3.0")
ø3.2 mm
(0.13")
ø3.2 mm
(0.13")
VS3 Series Sensor Hookups
10-30V dc
–
+
bu
bn
bk
Load
10-30V dc
–
+
bn
bu
bk
Load
10-30V dc
–
+
bu
bn
bk
Load
10-30V dc
–
+
bn
bu
bk
Load
Sensors with NPN Outputs
Cabled Models
Quick-Disconnect Models Quick-Disconnect Models
Sensors with PNP Outputs
Cabled Models
