E Series OMNI-BEAM™ Sensors
OMNI-BEAM sensors with electromagnetic relay outputs
Printed in USA
WARNING . . .
Not To Be Used for Personnel Protection
Never use these products as sensing devices for personnel protection. Doing so could lead to serious injury or death.
These sensors do NOT include the self-checking redundant circuitry necessary to allow their use in personnel safety applications. A
sensor failure or malfunction can cause either an energized or de-energized sensor output condition. Consult your current Banner
Safety Products catalog for safety products which meet OSHA, ANSI and IEC standards for personnel protection.
P/N 03540 rev. C
04/08
Features
SPDT electromechanical relay output for economy and high switching capacity
•
Operate from 24 to 250V ac (50/60Hz) or from 24 to 36V dc; all sensing modes
•
available
Modular design with interchangeable components, optional Pulse or Delay timing
•
logic modules
Sense and Load output indicator LEDs
•
Choice of prewired cable or SO-type quick-disconnect cable fitting
•
Cross-hole design for front, back, or side mounting, plus 30mm threaded base
•
mounting hub. Standard limit switch mounting hole spacing.
®
E71083
LR41887-17
Sensor
Head
Models
Sensing Mode
Range
Beam
Excess Gain
Beam Pattern
OSEE,
OSER
OPPOSED
45 m
(150‘)
Response: 20 ms ON/OFF
Repeatability: 0.4 ms
Infrared
880 nm
1
10
100
1 m
3.3 ft
10 m
33 ft
100 m
330 ft
0.1 m
0.33 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
OSBE & OSBR
Opposed Mode
50 m
150 ft
40 m
120 ft
30 m
90 ft
20 m
60 ft
10 m
30 ft
0
0
500 mm
1000 mm
1500 mm
500 mm
1000 mm
1500 mm
0
20 in
40 in
60 in
20 in
40 in
60 in
DISTANCE
Opposed Mode
OSBE and OSBR
OSED
DIFFUSE
450 mm
(18’’)
Response: 20 ms ON/OFF
Repeatability: 1 ms
Infrared
880 nm
1
10
100
10 mm
.4 in
100 mm
4 in
1000 mm
40 in
1 mm
.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
OSED
Diffuse Mode
500 mm
20 in
400 mm
16 in
300 mm
12 in
200 mm
8 in
100 mm
4 in
0
0
2.5 mm
5.0 mm
7.5 mm
2.5 mm
5.0 mm
7.5 mm
0
0.1 in
0.2 in
0.3 in
0.1 in
0.2 in
0.3 in
DISTANCE
Diffuse Mode
OSED
