VS2 Series Convergent Mode
page 3
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
VS2 Series Convergent Mode Sensor Dimensions
CL
2x ø2.2 mm
(0.09")
3.6 mm
(0.14")
4.7 mm
(0.19")
2.0 mm
(0.08")
8.0 mm
(0.31")
Green Power
Indicator
Yellow
Signal Indicator
(Receiver only)
12.0 mm
(0.47")
4.8 mm
(0.19")
25.1 mm
(0.99")
VS2CV30
21.2 mm
(0.84")
VS2CV15
20.6 mm
(0.81") 10.9 mm
(0.43")
150 mm (6") Pigtail
Accessories
Quick-Disconnect (QD) Cables
Style Models Length For Use With Dimensions Pinout
3-pin Pico Style
Straight
PKG3M-2
PKG3M-9
2 m (6.5')
9 m (30')
All VS2 Series sensors
with model suffix “Q”.
34.7 mm
(1.37")
9.6 mm
(0.38")
M8 x 1
Black Wire
Blue Wire Brown Wire
VS2 Series Mounting Brackets
SMBVS2RA
• Right-angle bracket
• 300 series stainless steel
5.5 mm
(0.22")
7.0 mm
(0.28")
2x 3.2 mm
(0.13")
0.9 mm
(0.04")
3.0 mm
(0.12")
3.0 mm
(0.12")
14.0 mm
(0.55")
4 x ø2.3 mm
(0.09")
8.0 mm
(0.32")
8.0 mm
(0.32")
8.0 mm
(0.32")
9.0 mm
(0.35")
20.0 mm
(0.79")
20.0 mm
(0.79")
