Q85 Series Sensors

Specifications, Q85VR3x Models

(24-240V ac or 12 to 240V dc, electromechanical output)

Sensing range:

See sensor descriptions by mode (page 3).

Sensing beam:

See sensor descriptions by mode (page 3).

Supply voltage:

24 to 240V ac, 50/60 Hz or 12 to 240V dc

(2 watts maximum). No polarity for power supply hookup.

Outputs (all models except emitters):

Q85VR3x models = SPDT e/m relay, on/off output
Q85VR3x-T9 models = SPDT e/m relay, programmable timer

Output relay specifications

Maximum switching power (resistive load): 90W, 750VA. Install

transient suppressor (MOV) across contacts switching inductive loads.

Maximum switching voltage (resistive load): 250V ac or 30V dc.
Maximum switching current (resistive load): 3A.
Minimum voltage and current: 5V dc, 10 mA.
Mechanical life: 50,000,000 operations.
Electrical life at full resistive load: 100,000 operations.
Maximum switching speed: 25 operations per second.
Closure time (no timing logic in use): 20 milliseconds max.
Release time (no timing logic in use): 20 milliseconds max.
Repeatability (no timing logic in use): 1 millisecond.
All sensors are protected against false pulse on power-up. (False
pulse protection circuit causes a 100 millisecond delay on power-up.)
Models are available with either ON/OFF output or 8 switch-select-
able output timing functions ("T9" model suffix).

Adjustments (all models except emitters):

Single-turn

SENSITIVITY

control potentiometer, accessible beneath

the ABS wiring chamber cover. Timing logic (for T9 models ) is
configured at a DIP switch. Pulse length and delay are set by a
single-turn potentiometer (under the wiring chamber cover). The
adjustable time range for both functions is 0.1 to 5 seconds; both
functions are automatically set to the same value. See page 6.

Response Time and Repeatability

are independent of signal strength:

see output relay specs. (above).

Status Indicators (all models except emitters):

Two LEDs, one red and one yellow, both top-mounted.
Red AID™ system (Alignment Indicating Device, US patent #4356393)
LED lights whenever the sensor "sees" its own modulated light, and
pulses at a rate proportional to the strength of the light signal.
Yellow indicator lights whenever the sensor's output is energized.

Construction:

Yellow Cycolac

ABS housing, plated steel hard-

ware. Acrylic lens. ABS cover for wiring/adjustments access. Rated
NEMA 1, 2, 3, 3S, 4, 4X, 6, 6P, 12, and 13; IEC IP67. It is the
customer's responsibility to maintain NEMA 6P integrity at the
conduit entrance(s) in use. Maximum wire size (for connection to
wiring terminals) is #14 AWG.

Vibration and Mechanical Shock:

meets Mil. Std. 202F require-

ments. Method 201A (Vibration: frequency 10 to 55 Hz. max., double-
amplitude 0.06-inch, maximum acceleration 10G). Method 213B Con-
ditions H & I (Shock: 75G with unit operating; 100G for non-operation).

Operating temperature range:

-25

to +55

C (-13

to +131

F).

Maximum relative humidity:

90% at 50

C (non-condensing).

Sensing range:

See sensor descriptions by mode (page 3).

Sensing beam:

See sensor descriptions by mode (page 3).

Supply voltage:

24 to 240V ac (50/60 Hz) or 12 to 240V dc

(2 watts maximum). No polarity for power supply hookup.

Outputs (all models except emitters)

Q85BW13x models = optically isolated solid-state switch
(as described below), on/off output
Q85BW13x-T9 models = optically isolated solid-state switch
(as described below), programmable timer

Optically-isolated SPST solid-state switch:
Maximum ratings: 250V ac, 250V dc, 300 mA.
Output saturation voltage: 3V at 300 mA, 2V at 15 mA.
Output leakage curent: <50 microamps.
Inrush current: 1 amp for 20 milliseconds, non-repetetive.
This output is not short-circuit protected.
Exercise care when making wiring connections.

All sensors are protected against false pulse on power-up: false pulse
protection circuit causes a 100 millisecond delay on power-up.
Models are available with either ON/OFF output or 8 switch-select-
able output timing functions ("T9" model suffix).

Adjustments (all models except emitters):

Single-turn

SENSITIVITY

control potentiometer, accessible beneath

Response Time and Repeatability

are independent of signal strength:

Q85BW13R

response time 6 ms on/3 ms off, repeatability 750

Q85BW13R-T9*

response time 12 ms on/9 ms off , repeatability 1 ms

Q85BW13LP

response time 4 ms on/4 ms off, repeatability 1 ms

Q85BW13LP-T9*

response time 10 ms on/10 ms off, repeatability 1 ms

Q85BW13D

response time 4 ms on/4 ms off, repeatability 1 ms

Q85BW13D-T9*

response time 10 ms on/10 ms off, repeatability 1 ms

Q85BW13DL

response time 4 ms on/4 ms off, repeatability 1 ms

Q85BW13DL-T9*

response time 10 ms on/ 10 ms off, repeatability 1 ms

*on/off operation (no timing in use)

Status Indicators (all models except emitters):

LEDs, one red and one yellow, both top-mounted.
Red AID™ system (Alignment Indicating Device, US patent #4356393)
indicator LED lights whenever the sensor "sees" its own modulated light,
and pulses at a rate proportional to the strength of the received light signal.
Yellow indicator lights whenever the sensor's output is conducting.

Construction:

Yellow Cycolac

ABS housing, plated steel hard-

Vibration and Mechanical Shock:

meets Mil. Std. 202F require-

ments. Method 201A (Vibration: frequency 10 to 55 Hz. max., double-
amplitude 0.06-inch, maximum acceleration 10G). Method 213B Condi-
tions H & I (Shock: 75G with unit operating; 100G for non-operation).

Operating temperature range:

-25

to +55

C (-13

to +131

F).

Maximum relative humidity:

90% at 50

C (non-condensing).

Specifications, Q85BW13x Models

(24 to 240V ac/12 to 240V dc, solid-state output)
