LS10 Light Screen System
•
Emitter and receiver pair produce a strobed array of modulated light
beams to produce a light screen
•
Simple, economical and highly reliable means of sensing small parts
which pass anywhere through the light screen
•
Light screen area measures 90 mm (3.5") high, and as wide as the
distance between the emitter and receiver
•
Fast, 1 millisecond response; output includes a 5-millisecond pulse
stretcher for interfacing reliability
•
Tight beam spacing for sensing small parts as small as 5.6 mm (0.22")
diameter
•
Totally self-contained; very rugged with totally encapsulated circuitry
•
Bipolar design offers the choice of NPN (current sinking) or PNP
(current sourcing) outputs from the same receiver; both outputs may
be used simultaneously
LS10E
100 to 1220 mm
(4" to 48")
4-Pin Mini-style QD
7.6 mm (0.30")
LS10RSR
3-Pin Mini-style QD
Models
Range
Cable*
Supply
Voltage
Output
Type
Minimum Resolution
4-Pin Mini-style QD
LS10ESR
100 to 200 mm
(4" to 8")
3-Pin Mini-style QD
12-30V DC
Bipolar
NPN/PNP
DO
5.6 mm (0.22")
LS10R
Infrared, 880 nm
LS10 Series Opposed Mode Emitter (E) and Receiver (R)
WARNING . . .
Not To Be Used for Personnel Protection
Never use these products as sensing devices for personnel protection. Doing so could lead to serious injury or death.
These sensors do NOT include the self-checking redundant circuitry necessary to allow their use in personnel safety
applications. A sensor failure or malfunction can cause either an energized or de-energized sensor output condition. Consult your current
Banner Safety Products catalog for safety products which meet OSHA, ANSI and IEC standards for personnel protection.
!
