Banner Q14 Series User Manual
Q14 series, Q14 series features, Warning

Q14 Series
Miniature self-contained dc photoelectric sensors
Printed in USA
P/N 45727A0B
Q14 Series Features
•
Self-contained dc sensors in miniature right-angle housings
•
IP54; NEMA 4 construction; hermetically-sealed optics
•
1.8 m (70") opposed range
•
Choose models for light operate or dark operate; choose either NPN (sinking) or
PNP (sourcing) output models
•
Choice of integral cable or quick-disconnect connector
•
Mounting bracket is included
*A model with a QD connector requires an optional mating cable (see page 4).
Q146E
Q146EQ
1.8 m
(70")
2 m (6.5')
3-Pin Pico-style Pigtail QD
10-30V dc
—
1
10
100
.1 m
.33 ft
1 m
3.3 ft
10 m
33 ft
.01 m
.033 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
Q14 Series
Opposed Mode
2.5 m
100 in
2.0 m
80 in
1.5 m
60 in
1.0 m
40 in
.5 m
20 in
0
0
100 mm
200 mm
300 mm
100 mm
200 mm
300 mm
0
4 in
8 in
12 in
4 in
8 in
12 in
DISTANCE
Q14 Series
Opposed Mode
Q14AN6R
Q14AN6RQ
—
2 m (6.5')
3-Pin Pico-style Pigtail QD
NPN
L.O.
L.O.
Q14AP6R
Q14AP6RQ
Q14RN6R
Q14RN6RQ
2 m (6.5')
3-Pin Pico-style Pigtail QD
2 m (6.5')
3-Pin Pico-style Pigtail QD
PNP
D.O.
D.O.
Q14RP6R
Q14RP6RQ
2 m (6.5')
3-Pin Pico-style Pigtail QD
WARNING . . .
Not To Be Used for Personnel Protection
Never use these products as sensing devices for personnel protection. Doing so could lead to serious injury or death.
These sensors do NOT include the self-checking redundant circuitry necessary to allow their use in personnel safety applications.
A sensor failure or malfunction can cause either an energized or de-energized sensor output condition. Consult your current Banner Safety
Products catalog for safety products which meet OSHA, ANSI and IEC standards for personnel protection.
!
Models
Range
Cable*
Supply
Voltage
NPN/
PNP
L.O./
D.O.
Excess Gain
Beam Pattern
Q14 Series Opposed-Mode Emitter (E) and Receiver (R)
Infrared, 880 nm
p/n 45727 Rev. C
