Banner SMBT18Y Mounting Bracket User Manual
Smbt18y mounting bracket, Features
SMBT18Y Mounting Bracket
For use with T18 sensors
Printed in USA
10/01
P/N 68502
Features
• Die-cast bracket for mounting into 18 mm holes
• Metal hex nut included
• Accommodates Euro-style QD connectors and cabled versions
25.4 mm
(1.00")
25.4 mm
(1.00")
ø15.3 mm
(60.3")
ø18.3 mm
(0.72")
17.25 mm
(68.0)
12.0 mm
(0.47")
2.0 mm
(0.08")
19.3 mm
(76.0)
M18
