U-GAGE ® T18U Series Sensor
WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering
Corp. will repair or replace, free of charge, any product of its manufacture found to be defective at the time it is returned
to the factory during the warranty period. This warranty does not cover damage or liability for the improper application of
Banner products. This warranty is in lieu of any other warranty either expressed or implied.
P/N 40124 rev. B
Quick-Disconnect Cables
Style Model Length Dimensions Pinout
4-Pin Euro Straight
MQDC-406
MQDC-415
MQDC-430 2 m (6.5’)
5 m (15’)
9 m (30’)
4-Pin Euro Right-Angle
MQDC-406RA
MQDC-415RA
MQDC-430RA 2 m (6.5’)
5 m (15’)
9 m (30’)
M12 x 1
ø 15 mm
44 mm
max.
Euro Straight
38 mm
max.
M12 x 1
ø 15 mm
Euro RA
38 mm
max.
Female
1 = Brown
2 = White
3 = Blue
4 = Black
2
3
4
1
Dimensions
Hookups
Key
1 = Brown
2 = White
3 = Blue
4 = Black
3
1
4
2
12-30V dc
–
+
Load
Load
4-Pin
1 = Brown
2 = White
3 = Blue
4 = Black
3
1
4
2
12-30V dc
–
+
Load
Load
4-Pin
1 = Brown
2 = White
3 = Blue
4 = Black
3
1
4
2
12-30V dc
–
+
Load
Load
4-Pin
1 = Brown
2 = White
3 = Blue
4 = Black
3
1
4
2
12-30V dc
–
+
Load
Load
4-Pin
1 = Brown
2 = White
3 = Blue
4 = Black
12-30V dc
–
+
3
1
4-Pin Euro
1 = Brown
2 = White †
3 = Blue
4 = Black †
† Not Used
Emitter* PNP (Normal Resolution)
PNP (High Resolution)
NPN (Normal Resolution)
NPN (High Resolution)
30 [1.18"]
15 [0.59"]
M12 x 1
Yellow LED Signal Strength Indicator
(Receiver Only)
Green LED Power Indicator
62.6
[2.47"]
M18 x 1
Thread 51.5
[2.03"]
* Emitter also functional with reverse polarity
30 [1.18"]
15 [0.59"]
M12 x 1
Yellow LED Signal Strength Indicator
(Receiver Only)
Green LED Power Indicator
62.6
[2.47"]
M18 x 1
Thread 51.5
[2.03"]
