M12 Class 2 Laser Emitter
6
P/N 52989 rev. C
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
bk
-
+
bn
bu
10-30V dc
Laser beam
enable
bk
-
+
bn
bu
10-30V dc
Laser beam
enable
M126E2LD Laser Diode Emitter
Unterminated Cable
M126E2LDQ Laser Diode Emitter
3-pin Pico-style Connector
Hookups
Mounting Brackets
SMB46X3
Bracket
Assembly
• Assembly with mounting block and
adjustable bracket
• Includes: 2mm Shortarm hex key
3/64" Shortarm hex key
4 Set screws
SMB127
Mounting
Block
• Mounting block only
• Includes: 3/64" Shortarm hex key
4 Set screws
31.8 mm
(1.25")
2x 7.1 mm
(0.28")
2x 11.4 mm
(0.45")
8x M5 or #10 clearance
14.0 mm
(0.55")
60 °
60 °
ø30.5mm
(1.20")
ø6.6mm
(0.26")
61.0 mm
(2.40")
61 mm to 64 mm
(2.4" to 2.5")
64.5 mm
(2.54")
36 mm
(1.4")
10.6 mm
(0.42 ")
36 mm
(1.4")
26.9 mm
(1.06")
22.9 mm
(0.90")
13.5 mm
(0.53")
6.4 mm
(0.25")
17.8 mm
(0.70")
17.8 mm
(0.70")
21.6 mm
(0.85")
18.5 mm
(0.73")
21.6 mm
(0.85") 5.1 mm
(0.20")
23.6 mm
(0.93")
12.9 mm
(0.508")
12.9 mm
(0.508")
2x M3
or #4 Clearance
3x #4-40 Thru
21.1 mm
(0.83")
10.6 mm
(0.42")
12.9 mm
(0.508")
