2 Installation
850 Professional IC – Anion – MCS – Prep 1
￭￭￭￭￭￭￭￭
15
3
High pressure pump
See Chapter 2.10.
4
Purge valve
See Chapter 2.10.1.
5
Inline filter
See Chapter 2.11.
6
Pulsation damper
See Chapter 2.12.
7
Injection valve
See Chapter 2.14.
8
Separation column
See Chapter 2.22.
When a guard column (see Chapter 2.21,
page 64) is used, it is installed between
injection valve and separation column.
9
10 MCS
11 Detector
12 Eluent output
Connection to the waste container.
13 Sample input
Connection to the sample vessel (single ves-
sel or sample changer).
14 Peristaltic pump
Pumps the sample. See Chapter 2.17.
15 Ultrafiltration cell
Is not included in the scope of delivery of
the 2.850.2110. Can be ordered as optional
accessories (as individual cell or with equip-
ment).
16 Sample output
17 Sample output
18 Sample degasser
See Chapter 2.13. Use optional.
19 Peristaltic pump
20 Regeneration solution input
Connection to the regeneration solution
bottle.
21 Regeneration solution output
Connection to the waste container.
22 Rinsing solution input
Connection to the rinsing solution bottle.
23 Rinsing solution output
Connection to the waste container.
