￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 9 Accessories
859 Titrotherm ￭￭￭￭￭￭￭￭ 33
Qty. Order no. Description
1 6.2727.010 SGJ intermediate cone
For reference and auxiliary electrodes in the measuring and titration
vessel with the lid 6.1414.010.
Material: PP
Outer diameter (mm): 18
Inner diameter (mm): 12
Length (mm): 25
1 6.3032.210 Dosing unit 10 mL
Dosing unit with integrated data chip with 10 mL glass cylinder and
light protection, mountable to a reagent bottle with ISO/DIN GL 45
glass thread. FEP tubing connection, antidiffusion buret tip.
Volume (mL): 10
1 6.6056.231 tiamo™ 2.3 Light CD: 1 license
tiamo™ 2.3 light PC program for controlling a titration system. Up to
two devices can be connected, graphical method editor with numer-
ous templates, layout manager for modifying the screen surface, pro-
fessional database with reevaluation, powerful report generator, no
parallel titration, no data export, 1 license, dialog languages German,
English.
1 6.9011.020 Thermoprobe for 859 Titrotherm
Temperature sensor made of glass for thermometric titration with
the 859 Titrotherm for aqueous or nonaqueous solutions.
Shaft material: Glass
Shaft material addition: PTFE
Measuring range: 0 ... 60
Measuring unit: °C
Shaft diameter top (mm): 12
Shaft diameter bottom (mm): 12
Shaft length to head (mm):
125
Minimum immersion depth
(mm): 20
Electrode plug-in head: Fixed cable (l = 1.2 m) with 7-pin
Lemo plug
1 6.2122.0x0 Mains cable with C13 line socket
IEC-60320-C13
Cable plug according to customer requirements.
Switzerland: Type SEV 12
6.2122.020
Germany, …: Type CEE(7), VII
