4 Installation
941 Eluent Production Module (2.941.0010)
￭￭￭￭￭￭￭￭ 29
4.7 Connecting the instrument
4.7.1 Connecting the instrument to the ion chromatograph
NOTE
The 940 Professional IC Vario must be switched off when connecting
the 941 Eluent Production Module!
Accessories For this step you need the following accessories:
￭ Controller cable (6.2151.000)
1 Insert the Mini DIN plug of the controller cable into the connection
socket on the rear of the instrument labeled Controller.
2 Insert the USB A plug of the controller cable into a USB socket of the
ion chromatograph.
4.7.2 Connecting the instrument to the power supply
WARNING
The power supply unit must not get wet. Protect it from liquids.
The power supply cable is three-core and provided with a plug with
grounding. If another plug has to be mounted, the yellow/green conduc-
tor (IEC standard) must be connected to the protective ground (protection
class I).
Accessories For this step you need the following accessories:
￭ For Switzerland, …: Power supply cable with IEC 60320 line socket,
type C13, with SEV 1011 plug, type 12 (6.2122.020), 1.5 m
￭ For Germany, …: Power supply cable with IEC 60320 line socket, type
C13, with CEE 7 plug, type VII (6.2122.040), 1.5 m
￭ For the USA, …: Power supply cable with IEC 60320 line socket, type
C13, with NEMA 5-15 plug, type 498 (6.2122.070), 1.5 m
Connecting the power supply cable
1 Plugging in the power supply cable
￭ Plug the power supply cable into the instrument's power socket.
