3.4 Installing the Dosino
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
12 ￭￭￭￭￭￭￭￭
IC equipment: Additional eluent for 941
2 Connecting the lower ports
1 Port 4 2 Adapter Port 4
3 Outlet tubing 4 Ultrapure water
5 Port 2
￭ Screw the FEP tubing that is connected to the ultrapure water
canister onto Port 2 of the Dosino.
￭ Attach the adapter to Port 4 of the Dosino and screw the fourth
FEP tubing onto the adapter.
￭ Fasten the other end of the FEP tubing to the waste container
with the adapter UNF / M6.
