3 Installation
IC equipment: Additional eluent for 941
￭￭￭￭￭￭￭￭
9
￭
Adapter for adsorber tube (6.1624.000)
￭
M6 threaded stopper (6.1446.040), included in the accessories for the
eluent bottle cap (6.1602.160)
Figure 6
Installing the ultrapure water canister cap without level sen-
sor
1 Connecting the FEP tubing
Fasten the tubing connection to the Dosino to the M6 opening.
￭
Insert the FEP aspiration tubing into the M6 opening.
￭
Screw the FEP tubing into the M6 opening.
2 Sealing the M8 opening
￭
Screw the M8 threaded stopper into the M8 opening.
3 Mounting the adsorber tube
￭
Fill the adsorber tube with soda lime and cotton.
￭
Fasten the adsorber tube in the large opening with the adapter.
