1 Introduction
846 Dosing Interface
￭￭￭￭￭￭￭￭ 1
1 Introduction
1.1 The 846 Dosing Interface in the Titrando system
The 846 Dosing Interface is a component of the modular Titrando system.
It is operated either by means of a Touch Control with a touch-sensitive
screen or through a computer with a corresponding software, e.g.
tiamo™ or MagIC Net™.
A Titrando system can contain numerous, various kinds of instruments.
The following figure provides an overview of the peripheral devices you
can connect to the 846 Dosing Interface.
MSB USB
Controller
Input 1 / 2
Sensors
PC Keyboard
Barcode
Reader
USB Hub
Balance
Touch Control
USB Sample Processor
Robotic Titrosampler
Printer
Personal Computer
Relay Box
Remote Box
846 Dosing Interface
Stirrer / Ti Stand Dosino Dosimat
USB/RS-232 Converter
867 pH Module
Titrando
On
Figure 1 The 846 Dosing Interface in the Titrando system
