3 Installation
846 Dosing Interface
￭￭￭￭￭￭￭￭ 19
Balance Cable
Mettler AE with interface option
011 or 012 6.2125.020 + 6.2125.010
also from Mettler: ME 42500
hand switch or ME 46278 foot
switch
Ohaus Voyager, Explorer, Analyti-
cal Plus Cable AS017-09 from Ohaus
Precisa balances with RS-232-C
interface 6.2125.080 + 6.2125.010
Sartorius MP8, MC1 6.2134.060
Shimadzu BX, BW 6.2125.080 + 6.2125.010
Operation with Touch Control
Connect the balance as follows:
1 Connect the 6.2148.050 USB/RS-232 Converter to the USB connec-
tor of the 846 Dosing Interface (Type A).
2 Use a suitable connecting cable (see preceding table) to connect the
balance to the USB/RS-232 Converter.
3 Switch on the Touch Control.
4 Switch on the balance.
5 Activate the RS-232 interface of the balance.
6 Configure the RS-232 interface of the RS-232/USB Box in the device
manager of the Touch Control as described in the Touch Control
manual.
3.5.4 Connecting a PC keyboard (only for operation with Touch Con-
trol)
The PC keyboard is used as an aid for text and numerical input. If you
operate the 846 Dosing Interface with the aid of the Touch Control, then
you can connect a PC keyboard with USB interface to the instrument.
Connect the PC keyboard as follows:
