MD‐DUCC FIRMWARE VERSION 1.1 SETTINGS
Copyright © 2011 Decimator Design Pty Ltd, Sydney, Australia
6
MENU = 17.
(LED 1 = Off, LED 2 = Off, LED 3 =
Red
, LED 4 = Off)
Audio Meter Group 1 Enable
LED 1 is Green when enabled, otherwise off when disabled. LED 2, 3 and 4 are off.
MENU = 18.
(LED 1 = Off, LED 2 = Off, LED 3 =
Red
, LED 4 =
Red
)
Audio Meter Group 2 Enable
LED 1 is Green when enabled, otherwise off when disabled. LED 2, 3 and 4 are off.
MENU = 19.
(LED 1 = Off, LED 2 =
Red
, LED 3 = Off, LED 4 = Off)
Audio Meter Group 3 Enable
LED 1 is Green when enabled, otherwise off when disabled. LED 2, 3 and 4 are off.
MENU = 20.
(LED 1 = Off, LED 2 =
Red
, LED 3 = Off, LED 4 =
Red
)
Audio Meter Group 4 Enable
LED 1 is Green when enabled, otherwise off when disabled. LED 2, 3 and 4 are off.
MENU = 21.
(LED 1 = Off, LED 2 =
Red
, LED 3 =
Red
, LED 4 = Off)
Audio Meter Style
LED 1
LED 2
LED 3
LED 4 Style
Off
Off
Green Green
Vertical Bar and Float
Off
Off
Off
Green
Vertical Bar
Off
Off
Green
Off
Vertical Float
Off
Off
Red
Red
Horizontal Bar and Float
Off
Off
Off
Red
Horizontal Bar
Off
Off
Red
Off
Horizontal Float
MENU = 22.
(LED 1 = Off, LED 2 =
Red
, LED 3 =
Red
, LED 4 =
Red
)
Audio Meter Reference Level
LED Status
LED
Description
Off
Green
Red
1
Reference Level
‐20dBFS
‐18dBFS
‐15dBFS
LED 2, 3 and 4 are off.
MENU = 23.
(LED 1 =
Red
, LED 2 = Off, LED 3 = Off, LED 4 = Off)
Audio Bar Scale
LED 1
LED 2
LED 3
LED 4 Reference Level
Off
Off
Off
Off
AES/EBU
Off
Off
Off
Green
VU
Off
Off
Green
Off
Extended VU
Off
Off
Green Green
BBC (IEC 2a)
Off
Green
Off
Off
EBU (IEC 2b)
Off
Green
Off
Green
DIN (IEC 2b)
Off
Green Green
Off
NORDIC (IEC 2b)
