MD‐DUCC FIRMWARE VERSION 1.1 SETTINGS
Copyright © 2011 Decimator Design Pty Ltd, Sydney, Australia 3
MENU = 5. (LED 1 = Off, LED 2 = Green , LED 3 = Off, LED 4 = Green )
Scaling Enable
LED 1 is Green when enabled, otherwise off when disabled. LED 2, 3 and 4 are off.
MENU = 6. (LED 1 = Off, LED 2 = Green , LED 3 = Green , LED 4 = Off)
Scaled Output Format
LED 1 LED 2 LED 3 LED 4 Scaled Output Format
Off Off Off Off 1. SD 720x487i59.94
Off Off Off Green 2. SD 720x576i50
Off Off Green Off 3. HD 1920x1080i60
Off Off Green Green 4. HD 1920x1080i59.94
Off Green Off Off 5. HD 1920x1080i50
Off Green Off Green 6. HD 1920x1080psf30
Off Green Green Off 7. HD 1920x1080psf29.97
Off Green Green Green 8. HD 1920x1080psf25
Green Off Off Off 9. HD 1920x1080psf24
Green Off Off Green 10. HD 1920x1080psf23.98
Green Off Green Off 11. HD 1920x1080p30
Green Off Green Green 12. HD 1920x1080p29.97
Green Green Off Off 13. HD 1920x1080p25
Green Green Off Green 14. HD 1920x1080p24
Green Green Green Off 15. HD 1920x1080p23.98
Green Green Green Green 16. HD 1280x720p60
Off Off Off Red 17. HD 1280x720p59.94
Off Off Red Off 18. HD 1280x720p50
Off Off Red Red 19. HD 1280x720p30
Off Red Off Off 20. HD 1280x720p29.97
Off Red Off Red 21. HD 1280x720p25
Off Red Red Off 22. HD 1280x720p24
Off Red Red Red 23. HD 1280x720p23.98
Red Off Off Off 24. 3G 1920x1080p60
Red Off Off Red 25. 3G 1920x1080p59.94
Red Off Red Off 26. 3G 1920x1080p50
