MD‐DUCC FIRMWARE VERSION 1.1 SETTINGS
Copyright © 2011 Decimator Design Pty Ltd, Sydney, Australia
2
MENU = 0.
(LED 1 = Off, LED 2 = Off, LED 3 = Off, LED 4 = Off)
Input Status (Button is disabled)
LED Status
LED
Description
Off
Green
Red
Orange
1
Input Format Detect
None
SD
HD
3G
MENU = 1.
(LED 1 = Off, LED 2 = Off, LED 3 = Off, LED 4 =
Green
)
HDMI Output Type
LED 1
LED 2
LED 3
LED 4 Output
Off
Off
Off
Off
DVI RGB 4:4:4, No audio is passed
Off
Off
Off
Green
HDMI RGB 4:4:4, 2 Audio channels passed
Off
Off
Green
Off
HDMI YCbCr 4:4:4, 2 Audio channels passed
Off
Off
Green
Green
HDMI YCbCr 4:2:2, 2 Audio channels passed
Off
Green
Off
Off
HDMI RGB 4:4:4, 8 Audio channels passed
Off
Green
Off
Green
HDMI YCbCr 4:4:4, 8 Audio channels passed
Off
Green
Green
Off
HDMI YCbCr 4:2:2, 8 Audio channels passed
MENU = 2.
(LED 1 = Off, LED 2 = Off, LED 3 =
Green
, LED 4 = Off)
Analogue Video Output
LED Status
LED
Description
Off
Green
Red
Orange
1
CVBS
CVBS
CVBS
Y
Pb
Pr
G
B
R
CVBS
C
Y
LED 2, 3 and 4 are off.
Please note:
1. Composite outputs will default to component (Y, Pb, Pr) when the output format is not 487i
or 576i.
2. 3G formats cannot be output on the Analogue Video output
MENU = 3.
(LED 1 = Off, LED 2 = Off, LED 3 =
Green
, LED 4 =
Green
)
Audio Output Type
LED Status
LED
Description
Off
Green
1
Audio Output
Analogue
AES/EBU
LED 2, 3 and 4 are off.
MENU = 4
(LED 1 = Off, LED 2 =
Green
, LED 3 = Off, LED 4 = Off)
Audio Group/Pair
LED 1
LED 2
LED 3
LED 4 Selected Audio Group/Pair to De‐embed
Off
Off
Off
Off
Group 1 Pair 1
Off
Off
Off
Green
Group 1 Pair 2
Off
Off
Green
Off
Group 2 Pair 1
Off
Off
Green
Green
Group 2 Pair 2
Off
Green
Off
Off
Group 3 Pair 1
Off
Green
Off
Green
Group 3 Pair 2
Off
Green
Green
Off
Group 4 Pair 1
Off
Green Green Green
Group 4 Pair 2
