4. Insert the Male End Cap into
the female end of the Short
Refl ector Bar. The Male End
Cap is preinstalled for a Right-
Hand confi guration.
3. Insert the male
end of the Short
Refl ector Bar into
the female end of
the second Long
Refl ector Bar.
NOTE: Sloping side of the Refl ector
Bars face outward.
3
4
FINAL ASSEMBLY
The ultrasonic beams are sent from the left arm of
the Puck to the top bar, then refl ected back, and
from the right arm of the Puck to the side bar, then
refl ected back as shown above.
The Puck can be moved to any point within the bars
as long as the left arm remains parallel to the top bar
and the right arm remains parallel to the side bar as
shown above.
U
SER’S
G
UIDE
— 5
Right-Hand
Confi guration
2nd Long Refl ector Bar Short Refl ector Bar
1st L
on
g R
efl
ect
or
B
ar
Left
Puck Arm
Right
Puck Arm
