RIGHT-HAND ASSEMBLY
Assemble the refl ector bars
as shown. Align the corner
connector at a 90° angle at the
top left corner of the plans.
5. Slide Female End Cap onto the male end of the fi rst Long Refl ector Bar.
The Female End Cap is preinstalled for a Right-Hand confi guration.
1. Insert the male end of the
Corner Connector into
the female end of the fi rst
Long Refl ector Bar.
2. Insert the male end of the second
Long Refl ector Bar into the female
end of the Corner Connector.
NOTE: Sloping side of the Refl ector
Bars face outward.
5
1
2
