Installing the Rapid Flow intake:
With the lid assembly put together the intake system can now be installed.
1. Place the lid assembly onto the top of the stock intake base. The lid will install onto the
base exactly as the stock lid does, utilizing the same mounting spots and the stock latches.
2. Prepare the stage 2 tube by sliding the band clamps onto the tube and then slide the sili-
cone tubes onto the correct end of the stage 2 tube. See the diagram below or the diagram
at the beginning of this instruction set to view the correct orientation.
Stock Lid Latches
OEM mounting points
Intake Installation
Attach to Lid Assembly
Attach to OEM Duct
