6
10. Use zip ties to secure the Rapid Power cable to the
tractor wiring harness. Be sure the cable will be safe
from moving parts (such as the starter/flywheel) or hot
exhaust system parts. Zip tie the module box to the
cable harness as shown.
rPm inSTAllATiOn
Tractors Stock Low Power Level
Total Horsepower
High Power Level
Total Horsepower
Magnum 215 175 HP ~193 ~210
Magnum 245 200 HP ~220 ~240
Magnum 275 225 HP ~248 ~270
Magnum 305 255 HP ~280 ~309
Magnum 335 275 HP ~303 ~330
This chart illustrates the approximate power increase when the Rapid Power
Module is set at the desired power level.~ Denotes an approximate value.
Warning: Do not remove
module while tractor is
running. Shut down machine
and then remove module.
