Remove stock pressure sensor male plug.

Plug the module male plug into the tractor fuel rail

pressure sensor.

Plug the stock male plug into module female plug.

Fuel Rail Pressure Sensor Plug

Fuel Rail Sensor Female Plug

Module Male Plug

Module Female Plug

Module Male Plug

rPm inSTAllATiOn
