Bowers & Wilkins DM310 - Manual

DM310
Stand-mount/Bookshelf loudspeaker system
Product Summary
● The DM310 is a completely new two-way vented box system designed to provide improved
performance for domestic hi-fi users through lower coloration, higher power handling and
greater dynamics.
● The 8in low frequency drive unit features a critically contoured re-inforced polypropylene
diaphragm, which is coupled to an energy damping PVC surround resulting in lower
coloration.
Technical highlights
● The use of a aluminium domed tweeter immediately distinguishes the two models. The specially
created 25mm (1in) tweeter enables high power handling to cope with the heavier usage
imposed on modern hi-fi systems. Frequencies in excess of 20kHz are within its range.
● Subtle changes to the cabinet such as the tweeter plate, and bevelled front edges of the cabinet,
help produce a dramatically more even frequency response. The B&W tradition of attention to
detail manifests itself other features, such as the reinforced low-frequency driven diaphragm, the
rigid die-cast chassis, and the provision for bi-wiring or bi-amplification.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Description
Drive Units
2-way 4th order, ported bass reflex
digital monitor system with bi-wiring/bi-
amplification facility
1 x 26mm high-frequency with metal
dome
1 x 200mm bass/midrange with rigid
die-cast chassis, reinforced propylene
diaphragm and 31mm high temperature
voice coil
Frequency Response
Sensitivity
Nominal Impedance
Power Handling
Dimensions
Finish
70Hz – 20kHz ± 2dB on reference
axis
90dB spl(2.83V 1m)
8 ohms
25W – 100W into 8 ohms on
unclipped programme
Height: 477mm Width: 262mm
Depth: 220mm
Anthracite, black ash or walnut vinyl
