SNOKONTROL Manual Rev B.
Page 9
3.OPERATING INSTRUCTIONS
3.1 Setup
3.1.1 Setting Up The System
Plug the AC to DC power supply to the system back panel and to the mains outlet.
Plug in your DMX cable(s) to your intelligent lighting as described in the fixtures respective
manual. For a quick lesson on DMX see the DMX Primer section in the Appendix of this manual.
3.1.2 Fixture Addressing
The controller is programmed to control 32 channels of DMX per fixture, therefore the fixtures
you wish to control with the corresponding SCANNER/PAGE buttons on the unit, must be
spaced 16 channels apart.
Fixture
Scanner
Number
(Page A/B)
DMX
Start
Address
Binary DIP Switch
Settings
(SET TO ON POSITION)
Fixture
Scanner
Number
(Page A/B)
DMX
Start
Address
Binary DIP Switch
Settings
(SET TO ON POSITION)
1 1A 1 1 13 7A 193 1, 7, 8
2 1B 17 1, 5 14 7B 209 1, 5, 7, 8
3 2A 33 1, 6 15 8A 225 1, 6, 7, 8
4 2B 49 1, 5, 6 16 8B 241 1, 5, 6, 7, 8
5 3A 65 1, 7 17 9A 257 1, 9
6 3B 81 1, 5, 7 18 9B 273 1, 5, 9
7 4A 97 1, 6, 7 19 10A 289 1, 6, 9
8 4B 113 1, 5, 6, 7 20 10B 305 1, 5, 6, 9
9 5A 129 1, 8 21 11A 321 1, 7, 9
10 5B 145 1, 5, 8 22 11B 337 1, 5, 7, 9
11 6A 161 1, 6, 8 23 12A 353 1, 6, 7, 9
12 6B 177 1, 5, 6, 8 24 12B 369 1, 5, 6, 7, 9
Please refer to your individual fixture’s manual for detailed DMX addressing instructions. The
table above refers to a standard 9-DIP Switch binary configurable device.
3.1.3 Pan & Tilt Channels
Because not all intelligent lighting fixtures are alike or share the same control attributes, the
Controller allows the user to assign the correct pan and tilt channel for every individual fixture.
1. Press and hold & until the display flashes.
2. Press then or button that represents the fixture
whose faders you would like to reassign.
3. Move the fader corresponding with the pan channel for the selected fixture.
4. Press the button to confirm.
5. Move the fader corresponding with the tilt channel for the selected fixture.
6. Press and hold & until the display flashes.
