KONTROL 6 Skywire Manual Rev. A
Copyright © 2014 Blizzard Lighting, LLC
2. INTRODUCTION
2.1 Features
•
DMX512/1990 Standard
•
2.4Ghz built-in wireless DMX transmitter
•
512 auto-assigning frequencies in 7 groups
•
18 preset scene/color banks, 9 per page
•
Record up to 18 chases with up to 200 scenes per chase
•
6 sliders for direct control of channels
•
Built-in microphone for music mode
•
Auto mode program controlled by fade time sliders
•
DMX out: 3-pin XLR
•
LED information display
•
Blackout function and instant strobe with variable speed fader
•
USB Backup/Restore of Data
2.2
General Overview
The controller is a universal intelligent lighting controller. It allows the con-
trol of 16 fixtures composed of 12 channels each and up to 18 programma-
ble scenes. Eighteen chase banks can contain up to 200 steps composed of
saved scenes or manual inputs in any order. Programs can be triggered by
music, automatically or manually. All chases can be executed at the same
time.
On the surface you will find various programming tools such as 6
RGBAW+UV universal channel sliders, quick access fixture and scene but-
tons, and an LED display indicator for easier navigation of controls and
menu functions.
2.3 Nifty, Spiffy Diagram (front)
1
2
3
4
5
6
7
8
9
11
12
16
17
18
13
14
20
10
19
15
