Orbiting
A-1 5975007 BARCOGRAPHICS 808s 160996
A
ORBITING
Orbiting (option)
Static pictures are very often shown on large screen projectors,
espectially in process control and presentation applications. Due to
the fact that the same picture information is shown for a long period
on the same place, picture tubes can be damaged by 'local burn-in'. To avoid this problem, BARCO has designed special Orbiting circuitry
which moves the picture very slow around a predefined screen area.
The orbiting circuitry has been designed using a very long cycle time
to make the movement of the projected image imperceptible.
Adjustment procedure :
The orbiting path is automatically added to the Random access
adjustment mode menu when installed.
Press
ADJUST to enter the adjustment mode and select Random.
The Random Access Adjustment Mode menu will be displayed.
Highlight ORBITING by pushing the joy stick forward or backward and
press
ENTER .
Select with or
then
to return.
RANDOM ACCESS
ADJUSTMENT MODE
PICTURE TUNING
GEOMETRY
CONVERGENCE
FOCUSING
COLOR SELECT
ORBITING
CONTR. MODULATION
SOFT EDGE
Orbiting Mode Toggle Switches
The orbiting module is provided with a three pin connector for
connection with the BARCO's BCl link option module, used in
multiple projector installations. For Orbiting, one projector operates
as master wheras the others operate as slave.
Master/Slave Toggle
Highlight 'CHANGE TO SLAVE' with the joy stick and press ENTER
to set the projector as Slave.
to return.
MASTER ORBITING
CHANGE TO SLAVE
MODE : ON
SPEED : FAST
ADJUST DEVIATION
SELECT WITH OR
THEN
DEVIATION ADJUST :
VERTICAL WITH OR
HORIZONTAL WITH OR
to return.
MASTER ORBITING
CHANGE TO MASTER
MODE : ON
SPEED : FAST
ADJUST DEVIATION
SELECT WITH OR
THEN
DEVIATION ADJUST :
VERTICAL WITH OR
HORIZONTAL WITH OR
Highlight 'CHANGE TO MASTER' with the joy stick and press
ENTER to set the projector as Master.
Orbiting ON/OFF toggle (only in Master Orbiting)
Highlight 'MODE : ON' with the joy stick and press ENTER to set the
ORBITING OFF.
Highlight 'MODE : OFF' with the joy stick and press
ENTER to set the
ORBITING ON.
to return.
MASTER ORBITING
CHANGE TO MASTER
MODE : ON
SPEED : FAST
ADJUST DEVIATION
SELECT WITH OR
THEN
DEVIATION ADJUST :
VERTICAL WITH OR
HORIZONTAL WITH OR
ENTER toggles between mode on and off.
EXIT returns to the Path selection menu.
