Pan Asia Sales Office
Bird Electronic Ltd
3A Unit 6 Tyrwhitt Road
Singapore 0820
Phone: 65 299 2537
Fax: 65 299 8509
Storage
No special preparations for storage are necessary other than to cover the equipment
to keep out dust and dirt. Store these units in a dry and dust-free environment
where the ambient temperature will remain within the -40°C to +45°C (-40°F to
+113°F) working range of the wattmeter.
Shipment
Load Resistor Wrap the RF connector with padding, and tape the padding securely in place. Pack
and brace the load in a suitable shipping container, a corrugated paper box should
suffice. It is not necessary to remove the dielectric coolant before shipping.
Meter Portion Disconnect the dc cable from the line section, and then wrap the meter with padding
and tape securely in place. The meter can be shipped in the same container as the
load portion.
Low Frequency
Line Section
If the low frequency line section is part of the equipment as an extra accessory, wrap
and tape it securely in padding before putting it in the container with the load and
meter.
Replacement Parts List
Item Qty. Description Part Number
1 1 RF Section Assy. 8130-015
2 1 Line Section Assy. 6151-006
3 1 RF Input Connector *See table
4 1 Meter Housing Assy. 6151-027
5 1 Meter 2080-002
6 1 Cable Assy. 4220-097-1
7 1 DC Plug 7500-076
8 1 Radiator Assy. 2400-053
9 4 Bumper Feet 5-049
10 1 Handle 2400-017
11 2 Clamp Band 7500-254
12 1 Diaphragm Cap 2400-050
13 1 Dielectric Coolant 5-030-1
14 1 Diaphragm 2400-015
Bird Model 6151A Termaline Wattmeter
12
