Maintenance
27
Bird 5011 and 5011-EF Sensors
Sensor Type Diode based terminated true
average power measurement
Power 10 µ W to 10 mW
(–20 dBm to +10 dBm)
Maximum Power 2 W avg.
125 W peak for 5 µs
Frequency Range
5011
5011-EF 40 MHz to 4 GHz
40 MHz to 12 GHz
Accuracy ±(5% of reading
*
+ 1.0 µW)
(excluding mismatch uncertainty)
(with correction factors for
5011-EF)
Peak / Average 12 dB max
Input Connector
5011
5011-EF N Male
Precision N Male
Output Connector Male DB-9 to host instrument
Input Impedance 50 Ohms (nominal)
Input VSWR:
5011
Typical
Maximum
5011-EF
Typical
Maximum
1.03 (36.6 dB return loss)
1.20 (20.8 dB return loss)
1.05 (32.0 dB return loss)
1.25 (19.1 dB return loss)
