Bird Model 5000 Digital Power Meter
26
Bird 5010 Sensor
Sensor Type /
Elements
*
Bird Thruline directional dual-
element line section. Uses two
Bird DPM Elements.
Power
†
0.1 to 1,000 W
Frequency Range
†
2 MHz to 3600 MHz
Accuracy With DPM Elements:
±5% of reading 15 to 35 °C RSS
±7% of reading –10 to 50 °C RSS
Peak / Average 10 dB maximum with DPM
Elements.
Settling Time < 2.5 seconds
Connectors QC Type, Female N normally
supplied
Insertion VSWR 1.05:1 up to 1 GHz (with N
connectors).
Dimensions 2.5”H x 5.0”W x 2.0”D
(58 x 127 x 51 mm)
Weight 1.25 lb. (0.57 kg) nominal with
elements.
* RFL element power must be 1/10 of FWD power.
† Power and frequency range based on selected elements.
