Bird Technologies 5000 Series - Manual (Page 21)

Introduction
7
Optional Equipment
Directional Power Sensor (DPS) — Bird 5010,
requires two DPM Elements. As a Thruline Sensor,
the DPS measures both forward and reverse power,
enabling the DPM to display VSWR and other match
measurements. Includes interface cable.
Terminating Power Sensors (TPS)— Highly accurate
terminating sensors; do not require elements.
The Bird 5011 frequency range is 40 MHz – 4 GHz.
The 5011-EF frequency range is 40 MHz – 12 GHz.
Includes interface cable.
Automobile Cigarette Lighter Adapter —
(P/N 5A2238-1) Connects the DPM to a standard 12V
automotive cigarette lighter jack.
Soft Carry Case — (P/N 5000-030) Convenient and
protective. Cutouts allow for operation without
removal from the case.
Hard Carry Case — (P/N 5000-035) Protective case
holds DPM, sensor, and accessories.
Attenuators & Accessories — A variety of
attenuators and connectors for measuring large
powers with the TPS. For a complete list, see page 23.
