meter may be used to measure several RF transmission lines without
interruption of RF lines for insertion of the Thruline Wattmeter. Additional
RF line sections are available (see figure 7).
The RF line section of the Model 43 lends itself very readily to panel type
mounting. A layout for the panel mount cut is given in figure 8. The thickness
of the panel should be about 1/4 inch. On panels less than this, build up the
thickness with pads or washers to achieve a flush-face mounting. Cable
connections are simplified because the RF line section may be mounted in
any convenient direction. Attach the line section so that the finger catch is
in the most accessible position.
Installation
21
