4
2. After centering the contact, bend the contact bar
slightly toward the center of the element socket
bore, so that the profile of the element contact is
visible when viewing the element socket from the
top of the socket bore.
Note:
If the contact is accidently moved too
far, the element will not slide into the socket.
Move the contact back into the recessed area
and repeat the process.
Out put
R e fle c te d
F o rw a rd
In pu t
Out put
