Reference
11
shSaOccupiedBandwidthConfig Structure
shSaChannelConfig Structure
shSaAdjacentChannelConfig Structure
shSaDemodSignalConfig Structure
shSaZeroSpanConfig Structure
OccupiedBandwidthType Enumerated integer of type
shSaOccupiedBWType indicating the
method percent or dBc) used to set the
power level for the measurement.
OccupiedBandwidthLevel Specifies the power level used to
calculate the occupied bandwidth.
ChannelWidth Unsigned 64 bit variable (type Frequency)
Specifies the channel width in Hz.
ChannelWidth Unsigned 64 bit variable (type Frequency)
Specifies the channel width in Hz.
AdjacentChannelWidth Unsigned 64 bit variable (type Frequency)
Specifies the adjacent channel width in Hz.
ChannelSpacing Unsigned 64 bit variable (type Frequency)
Specifies the channel spacing in Hz.
Spacing is measured from channel center
to adjacent channel center.
ModulationType Enumerated integer of type shSaDemod
Bands indicating the modulation type for
demodulation measurements.
SweepTime Unsigned long integer specifying the
sweep time for the zero span (time
domain) measurement. The sweep time
determines the effective sample interval
for the measurement. The sample
interval is given as
SweepTime/( SA_MAX_DATA_SIZE-1)
