Bird 8860 Series Semiconductor Termaline Coaxial Load Resistor
2
Figure 1
Bird 8860 Series
Outline Drawing
MTG. HOLE
DETAIL
13/32”
(10 mm)
3/32”
(2.4 mm)
3/8”
(9.5 mm)
(4) MTG. HOLES
SEE DETAIL
4.5”
(114 mm)
7.5”
(190 mm)
15-7/8”
(403 mm)
13-1/8”
(333 mm)
3”
(75 mm)
DEPENDS ON
CONNECTOR
INTERLOCK
THERMOSWITCH
(OPTIONAL)
VENT PLUG
15-1/4”
(387 mm)
